SENECT | ONE

Item number: 100

Dimensions: 191 x 140 x 60 mm
Sensor-Input: 1 x Universal-Input (compatible to all Senect Sensors)
Output-Ports: 3 x Aktuator-Output
Ingress protection: IP54
Data transmission: 2.4 GHz WLAN, remote access via dynamic DNS, port forwarding and IPv4

Category: Controller

Powersupply
Mains Connector

There are variations of this item. Please select the variation you wish.


Multifunctional Aquaculture Controller

One controller for all:

  • Monitoring and regulating of one parameter (e.g. Oxygen)
  • Feeding
  • Monitoring & alarming
  • Versatile in its applicability: ponds, raceways, mesocosms and recirculating aquaculture systems (RAS)
  • Scalable and combineable: many units can be combined to one software system
  • Wireless data transmission via WLAN ? Remote access and alarm via smartphone
  • Easy DIY installation - easy operation


Regulation. Feeding. Monitoring.

Example: Oxygen regulation and monitoring

  • Sensor Plug: Oxygen-Sensor O2S
  • Actuator Plug 1: Oxygen Valve MVO
  • Actuator Plug 2: Hatchery-Fry Feeder
  • Actuator Plug 3: e.g. Light, alarm lamp, etc.
    ?Data evaluation & settings via WLAN & App
    ?Notifications via push message & E-Mail


Clever regluation of aeration

  • Measurement of the oxygen concentration with the low-maintenance and long-term stable optical SENECT O2-Sensor O2S.
  • If the oxygen concentration sinks below a treshhold, an aerator or solenoid valve depending on the aeration mode is switched on (24 v DC devices directly, 230 V AC devices via the optional Power Switch)
  • Multiple regulations are possible! For example, if the oxygen concentration falls below 70% saturation, an aerator is switched on. If the oxygen concentration falls further to less than 60%, additionally technical oxygen supply is switched on via a solenoid valve.

SENECT|ONE - Cost saving, ressource-efficient and versatile.



Automatic feeder control

  • All typical feeders can be connected (AC feeders via the optional Power Switch)
  • Intelligent control of feed portion and timing
  • Calibration: Values in (Kilo-) Gramm
  • Interruption of feeding, if O2-levels are too low
  • Comfortable operation via smartphone, tablet or PC

Feeding - Controlled, intelligent and as often as you like.




Installation

  • Easy and cost-effective
  • No data cables - saves costs and diminishes failure causes
  • Only a power supply necessary


Mounting. Plugging connectors in. Define the settings. - Ready!


Ideally suited for fish or shrimp ponds

  • Only one control unit per pond executing all required functions:
    • Control of aeration
    • Control of feeding
    • Remote monitoring and alarming
  • Cost effecitve ? at the aquisition and during the operation:
    • Small control unit: reduced to the minimum
    • No data cables necessary
    • Intelligent control reduces energy consumption and wearout aerators


The SENECT System

  • A modular, decentralized control system:
    • Simple expansion of existing plants
    • Increased safety through small, distributed units
    • Inexpensive installation due to low cabling effort
  • Wireless data connection via WLAN
    • Updates via WLAN: Install new features free of charge
    • Inexpensive installation: No network cables necessary



The SENECT Control App

The SENECT Control App is a software for smartphones, tablet-PCs and computer (PCs and Apple), with which the SENECT control units can be operated.

With the SENECT Control App the control units are connected with your wireless network and you can visualize sensor measuments and the status of the output ports live and receive alarm-messages.

For example, the SENECT Control App sends you an alarm via a push-message on your phone, if a parameter falls below its treshold or if the filter stops is in the emergency stop mode.

Everything at first sight: With the SENECT Control App you can see all sensor measurements and the status of the output ports (e.g. solenoid valve on or off) clear displayed on one page. So that you always keep track of your parameters and devices.




Benefit from the advantages of the SENECT Control App:
  • Linking-up your control units
  • Easy and clear visualization overview about measured parameters and output states
  • Receiving alarm messages on your mobile phone


Download the SENECT Control App for Android, iOs or Windows devices.

Now available at the Google Playstore, App Store or here.




The SENECT Control App needs to detect the available WLAN networks the permission to use the location service of your device. No personal data will be saved or used.

More informations are in our privacy policy.



Overview SENECT Controller

SENECT
ONE

SENECT
TWO

MONITOR
FOUR

FILTER
CONTROL

AQUACULTURE
CONTROL
Basic

AQUACULTURE
CONTROL
Pro

Sensor-Input-Ports

1 x

2 x

4 x

2 x Water level sensors,

1 x Cover switch

3 x

6 x

Actuator outputs

3 x

2 x

-

2 x

2 x

5 x

High-Power 24V Output

-

-

-

1 x

1 x

1 x

230V Output

-

-

-

3 x

3 x

3 x

Power supply

60 W

60 W

15 W

150 W / 300 W

150 W / 300 W

150 W / 300 W

Ingress protection

IP54

IP54

IP54

IP54

IP54

IP54




Product weight: 1,32 Kg
